SUP-P260-M2 Slurry level meter are completely sealed for submersion in liquid, can be used to measure water level, well depth, groundwater leverl and so on, common accuracy is 0.5%FS,with voltage or 4-20mA output signalsused. Durable 316 SS construction for reliable, long life in harsh environments.
Features
Range: 0 ~ 100m
Resolution: 0.5% F.S
Output signal: 4~20mA
Power supply: 24VDC
-
Features
- Non-clogging and damage resistant to floating solids
- Durable 316 SS construction for reliable, long life in harsh environments
- 1/2 inch NPT threaded connection, allows the unit to be installed in a pipe/conduit
- Diaphragm is protected from physical damage and turbulence
- Added weight helps hold transmitter in place
- Excellent chemical compatibility for wide application use
-
Specification
| Product | Slurry level transmitter |
| Model | SUP-P260-M2 |
| Measuring range | 0m~0.5m···100m |
| Pressure overload | ≤2 times full range |
| Display resolution | 0.5% |
| Stability | ±0.2%FS/year |
| Output signal | 4mA-20mA |
| Pressure type | G(gape pressure) |
| Power supply | 12VDC-30VDC |
| Conpensation temperature | ≤2m:0℃~50℃
≥2m:-10℃~60℃ |
| Medium temperature | -30℃~65℃ |
| Ingress protection | IP68 |
-
